Cosmetic Additive Refractive window dryer

Principles ：

Wantai Cosmetic Additive Refractive window dryer is a new thin layer drying technology. Under normal pressure, 95-97 ℃ hot water is used as a thermal source. The transparent polyester film is covered on the surface of the hot water. The wet material is sprayed on the polyester film, the heat is passed to wet material through the polyester film, and the moisture of the material evaporation is eliminated by the exhaust fan, and the separation of the material from the polyester film is separated to the end point of dryness.

Cosmetic Additive Refractive window dryer system features：

1) Low energy consumption;

2) For dry liquid materials, there is no need to pre-concentrated or processing of gum for raw materials, etc.;

3) Continuous operation and production

4) Low water consumption;

5) Easy to clean;

6) Simple control and easy operation;

7) Due to the use of flexible drying and high product quality, it can maintain the original color and fragrance;

8) Operations under low temperature and normal pressure conditions, greatly reduces the oxidation of the product;

9) The product has a high loosening dump density, which reduces packaging and transportation costs.

Cosmetic Additive Refractive window dryer Drying conditions：

The factors that restrict dryness on Cosmetic Additive Refractive window dryer include air inlet temperature, exhaust temperature, air humidity, dry air volume, material liquid treatment, water evaporation, dry room diameter, dry room volume, particle diameter.

When designing the above factors, according to the characteristics of dry materials, the particle size and processing of the required product are determined, especially the diameter and volume of the dry chamber. Because they are indispensable factors, it is not possible to make too many adjustments based on this. Therefore, before the design of the Refractive window dryer, it is very necessary to select appropriate drying conditions on a small test machine.

Cosmetic Additive Refractive window dryer Models & Specifications：

The WTFD Cosmetic Additive Refractive window dryer is mainly composed of feeding mechanism, outlet mechanism, special conveyor belt, sink, heating water tank, circulating water pump, feed metering pump, air atomized nozzle feeding device, rack, box, etc.

The refractive window dryer mainly has the following specifications and parameters:
