1、 Introduction to Mango Powder Drier
Mango powder contains the effect of dispelling diseases and relieving cough, which has an auxiliary treatment effect on cough, phlegm, asthma, and other symptoms. Eating mango powder has the effect of clearing the intestines and stomach, and has a therapeutic effect on motion sickness and preventing hypertension.
2、Mango Powder Dryer Technical Principles ：
Wantai Mango Powder Dryer is a new thin layer drying technology. Under normal pressure, 95-97 ℃ hot water is used as a thermal source. The transparent polyester film is covered on the surface of the hot water. The wet material is sprayed on the polyester film, the heat is passed to wet material through the polyester film, and the moisture of the material evaporation is eliminated by the exhaust fan, and the separation of the material from the polyester film is separated to the end point of dryness.
According to the study, when the aquatic material is placed on the surface of the polyester film, the part between the water in the material and the polyester film forms a channel that allows infrared energy to pass. The thermal energy is transmitted to the material by conduction and radiation at the same time, and the material is heated and the water is evaporated. Due to evaporation and exhaust cooling, the temperature of the material rarely exceeds 75 ° C. After the material is dried, the infrared channel will be closed. The heat can only be transmitted in a transmission. Since the polyester film is a poor conductor of heat, dry samples can avoid excessive heating.
3、Mango Powder Dryer Application advantages：
Suitable for paste, mud-shaped liquid material, especially the drying effect of thermal material.
1. Compact equipment, small volume, high production efficiency, and continuous production.
2. Drying strength, low energy consumption, and high thermal efficiency.
3. Fast drying speed, short material staying time, and high drying quality.
4. Gentle and fast drying process, retain the original product effective ingredients, and have the same quality effect as frozen and dry. The drying speed and cost are only one tenth.
4、Mango Powder Dryer Models & Specifications：
The WTFD Mango Powder Dryer is mainly composed of feeding mechanism, outlet mechanism, special conveyor belt, sink, heating water tank, circulating water pump, feed metering pump, air atomized nozzle feeding device, rack, box, etc.
The refractive window dryer mainly has the following specifications and parameters:
Serial Number | model | Installed power(Kw) | Circulating water volume（L） | Configure heat(Kcal) | Overall dimensions (length × wide × Height (mm) | notes |
1 | WTFD-1650-4880 | 15 | 750 | 15×104 | 8690×2200× 2700 | Compressed air, Pressure 0.7kg/cm3
|
2 | WTFD-1650-9760 | 19.2 | 1500 | 30×104 | 13930×2200× 2700 |
3 | WTFD-1650-14640 | 26.7 | 2250 | 45×104 | 19170×2200× 2700 |
4 | WTFD-1650-19520 | 33 | 3000 | 60×104 | 24410×2200× 2700 |
5 | WTFD-1650-24400 | 45 | 3750 | 75×104 | 29650×2200× 2700 |
