1、 Introduction to Shrimp Powder
Shrimp powder is a small granular or fibrous substance made from shrimp meat or shrimp skin, heated or microwave dried, and ground.
The main function of shrimp powder is to supplement calcium and protein. There are many kinds of nutrient elements in shrimp powder. In addition to calcium and protein, there are also carotene and Chitin.
2、Shrimp Powder Refractive window dryer Application advantages：
Suitable for paste, mud-shaped liquid material, especially the drying effect of thermal material.
1. Compact equipment, small volume, high production efficiency, and continuous production.
2. Drying strength, low energy consumption, and high thermal efficiency.
3. Fast drying speed, short material staying time, and high drying quality.
4. Gentle and fast drying process, retain the original product effective ingredients, and have the same quality effect as frozen and dry. The drying speed and cost are only one tenth.
3、Shrimp Powder Refractive window dryer Technical Principles ：
Wantai Shrimp Powder Refractive window dryer is a new thin layer drying technology. Under normal pressure, 95-97 ℃ hot water is used as a thermal source. The transparent polyester film is covered on the surface of the hot water. The wet material is sprayed on the polyester film, the heat is passed to wet material through the polyester film, and the moisture of the material evaporation is eliminated by the exhaust fan, and the separation of the material from the polyester film is separated to the end point of dryness.
According to the study, when the aquatic material is placed on the surface of the polyester film, the part between the water in the material and the polyester film forms a channel that allows infrared energy to pass. The thermal energy is transmitted to the material by conduction and radiation at the same time, and the material is heated and the water is evaporated. Due to evaporation and exhaust cooling, the temperature of the material rarely exceeds 75 ° C. After the material is dried, the infrared channel will be closed. The heat can only be transmitted in a transmission. Since the polyester film is a poor conductor of heat, dry samples can avoid excessive heating.
4、Shrimp Powder Refractive window dryer Drying conditions：
The factors that restrict dryness on Shrimp Powder Refractive window dryer include air inlet temperature, exhaust temperature, air humidity, dry air volume, material liquid treatment, water evaporation, dry room diameter, dry room volume, particle diameter.
When designing the above factors, according to the characteristics of dry materials, the particle size and processing of the required product are determined, especially the diameter and volume of the dry chamber. Because they are indispensable factors, it is not possible to make too many adjustments based on this. Therefore, before the design of the Refractive window dryer, it is very necessary to select appropriate drying conditions on a small test machine.
