Poultry Manure Dryer

1、 Overview of poultry manure dryer

The poultry manure dryer is suitable for areas with developed large, medium, and small aquaculture industries. According to the requirements of the drying products, different heat sources can be used. For example, gas generators, direct heating hot air furnaces, indirect hot air furnaces, thermal oil, electric heating, steam, etc. This equipment is suitable for chicken manure, duck manure, livestock manure, slaughtering waste, etc. with a moisture content of less than 65%. It has good effects on opening up feed resources, reducing feeding costs, and reducing environmental pollution.

2、 Performance characteristics of poultry manure dryer

1. Production process: fresh chicken manure containing 65% water can be dried into pure poultry manure Manure containing less than 13% water through high-temperature drying, disinfection, sterilization, decomposition and other processes.

2. Dried finished product: After testing and certification by the scientific research department, the nitrogen content of the dried fertilizer is 2.6%, phosphorus content is 3.5%, potassium content is 2.5%, crude protein content is 16-25%, and organic matter content is 45%. It is a fertilizer choice for planting pollution-free green food and can also be used for feeding fish, cattle, pigs, etc.

3. The rotary drum drying has a high degree of mechanization, a large production capacity, and can operate continuously.

4. The structure is excellent, simple, and the material runs smoothly through the resistance of the cylinder, making it easy to operate.

5. Less faults, low maintenance costs, and low power consumption.

6. Wide application range, good uniformity of product drying.

7. Drying can also achieve the purpose of sterilization and deodorization.

3、 Working principle of poultry manure dryer

The poultry manure dryer mainly consists of a heat source, a feeding machine, a feeding machine, a rotating drum, a material crushing device, a discharge machine, an induced draft fan, a discharger, and a power distribution cabinet. After the dehydrated wet material enters the dryer, it is evenly dispersed in the dryer and fully contacts with hot air under the flipping of the uniformly distributed plate reader in the drum, accelerating the heat and mass transfer during drying. After the drying is completed, the material is transported to another section of the star discharge valve of the dryer to discharge the finished product under the action of the inclined plate and the hot air.
