1、 Overview of Barley Green Juice
Barley green juice is a liquid beverage made from barley seedlings. When barley seedlings grow to 20-30 cm, they are rich in nutrients. Using seedlings from this stage as raw materials can also exert their effects and be beneficial to the human body.
Barley green juice has the effect of promoting human metabolism, maintaining acid-base balance in the body, and also has good therapeutic effects on antioxidant and intestinal cleaning.
2、Barley green juice dryer Scope of Application
After testing and production, the liquid paste material refractive window dryer is the most suitable for heat sensitive materials, mainly including:
Vegetables: spinach, asparagus, tomatoes, Broccoli, pumpkin, etc
Nutrients: Spirulina, blue-green algae, seaweed, barley grass juice, yeast, etc
Beverages: coffee, tea, etc
Waste: soybean residue, muddy materials, etc
3、Barley green juice dryer Models & Specifications:
The WTFD Barley green juice dryer is mainly composed of feeding mechanism, outlet mechanism, special conveyor belt, sink, heating water tank, circulating water pump, feed metering pump, air atomized nozzle feeding device, rack, box, etc.
The refractive window dryer mainly has the following specifications and parameters:
Serial Number | model | Installed power(Kw) | Circulating water volume(L) | Configure heat(Kcal) | Overall dimensions (length × wide × Height (mm) | notes |
1 | WTFD-1650-4880 | 15 | 750 | 15×104 | 8690×2200× 2700 | Compressed air, Pressure 0.7kg/cm3 |
2 | WTFD-1650-9760 | 19.2 | 1500 | 30×104 | 13930×2200× 2700 | |
3 | WTFD-1650-14640 | 26.7 | 2250 | 45×104 | 19170×2200× 2700 | |
4 | WTFD-1650-19520 | 33 | 3000 | 60×104 | 24410×2200× 2700 | |
5 | WTFD-1650-24400 | 45 | 3750 | 75×104 | 29650×2200× 2700 |
