1、 Introduction to Potato Flour
Potato powder can be formulated scientifically and added with corresponding nutritional ingredients to make full nutrition, multi variety and multi flavor convenience food, and can also be used as "additive" to make cold drink food, convenience food, puffed food, and a variety of nutritional food and leisure food for special groups (hyperlipidemia, diabetes patients, the elderly, women, children, etc.).
2、Overview of Potato Flour Dryer
Potato Flour Dryer uses 95 ℃ hot water as the drying medium to perform Refractive window drying on liquid paste materials. The moisture content is dried from 90% to 5%, and the drying time is only about 5 minutes. However, conventional heat pump drying, hot air drying, and freeze-drying require more than 12 hours or even longer. Therefore, when the liquid paste material is dried, it can maintain 94% vitamin C and natural color, nutrition, flavor, and aroma. The quality of the products it produces is comparable to that of freeze-dried products, but the energy consumption is less than one-tenth of that of freeze-dried products.
3、Potato Flour Dryer Application advantages:
Suitable for paste, mud-shaped liquid material, especially the drying effect of thermal material.
1. Compact equipment, small volume, high production efficiency, and continuous production.
2. Drying strength, low energy consumption, and high thermal efficiency.
3. Fast drying speed, short material staying time, and high drying quality.
4. Gentle and fast drying process, retain the original product effective ingredients, and have the same quality effect as frozen and dry. The drying speed and cost are only one tenth.
4、Potato Flour Dryer Models & Specifications:
The WTFD Potato Flour Dryer is mainly composed of feeding mechanism, outlet mechanism, special conveyor belt, sink, heating water tank, circulating water pump, feed metering pump, air atomized nozzle feeding device, rack, box, etc.
5、Potato Flour Dryer Models & Specifications:
The WTFD Potato Flour Dryer is mainly composed of feeding mechanism, outlet mechanism, special conveyor belt, sink, heating water tank, circulating water pump, feed metering pump, air atomized nozzle feeding device, rack, box, etc.
The refractive window dryer mainly has the following specifications and parameters:
Serial Number | model | Installed power(Kw) | Circulating water volume(L) | Configure heat(Kcal) | Overall dimensions (length × wide × Height (mm) | notes |
1 | WTFD-1650-4880 | 15 | 750 | 15×104 | 8690×2200× 2700 | Compressed air, Pressure 0.7kg/cm3 |
2 | WTFD-1650-9760 | 19.2 | 1500 | 30×104 | 13930×2200× 2700 | |
3 | WTFD-1650-14640 | 26.7 | 2250 | 45×104 | 19170×2200× 2700 | |
4 | WTFD-1650-19520 | 33 | 3000 | 60×104 | 24410×2200× 2700 | |
5 | WTFD-1650-24400 | 45 | 3750 | 75×104 | 29650×2200× 2700 |
